Aluminum Alloy 5005

An Aluminum Alloy is a composition consisting mainly of aluminum to which other elements have been added, including iron, copper, magnesium, silicon, and zinc. The addition of elements to the aluminum gives the alloy improved strength, workability, corrosion resistance, electrical conductivity, and/or density, compared with the pure metallic element.

Aluminum Alloy 5005 is commercially available in different forms including sheet, plate, coil, strip, tube, and customized fabricated products. Common tempers include 5005-O, 5005-H12, 5005-H14, 5005-H32, 5005-H34, H36, and H38, allowing customers to select the required balance between strength, flexibility, and processing performance. This alloy is widely supplied for architectural panels, building facades, roofing systems, electrical components, HVAC equipment, signage, food processing equipment, automotive parts, and decorative anodized products.

The main advantages of Aluminum Alloy 5005 include excellent resistance to atmospheric corrosion, high recyclability, low density, good welding performance, easy fabrication, and compatibility with anodizing processes. Due to its combination of mechanical performance and aesthetic appearance, Aluminum 5005 is an ideal material for manufacturers looking for a reliable aluminum alloy for long-term industrial applications. International buyers can source Aluminum Alloy 5005 in various dimensions, finishes, and tempers according to project requirements.

Aluminum Alloy 5005 Technical Specifications

Property	Specification
Alloy Designation	Aluminum Alloy 5005
Alloy Series	5000 Series Aluminum-Magnesium Alloy
Standard Designation	AA5005 / UNS A95005 / EN AW-5005
Main Alloying Element	Magnesium (Mg 0.5–1.1%)
Aluminum Content	Balance (Approx. 97–99.5%)
Density	Approx. 2.70 g/cm³
Tensile Strength	105–200 MPa (depending on temper)
Yield Strength	35–186 MPa (depending on temper)
Corrosion Resistance	Excellent atmospheric corrosion resistance
Weldability	Very Good
Surface Treatment	Excellent for anodizing and decorative finishing
Available Forms	Sheet, Plate, Coil, Strip, Tube, Profile

IF YOU ARE WILLING TO BUY ALLUMINIUM ALLOY 5005 FROM IRANIAN SUPPLIERS, PLEASE SCROLL DOWN AND SUBMIT YOUR REQUEST.

Rated 0 out of 5

0 reviews

Rated 5 out of 5

0

Rated 4 out of 5

0

Rated 3 out of 5

0

Rated 2 out of 5

0

Rated 1 out of 5

0

Reviews

Clear filters

There are no reviews yet.

Be the first to review “Aluminum Alloy 5005”

You must be logged in to post a review.

FAQ Aluminum Alloy 5005

Aluminum Alloy 5005 is used in architectural panels, building facades, roofing, signage, electrical applications, HVAC equipment, food processing equipment, decorative parts, and general sheet metal fabrication.

The main advantages include excellent corrosion resistance, good weldability, lightweight structure, good formability, high-quality anodizing capability, and attractive surface appearance.

Aluminum 5005 can be supplied as sheets, plates, coils, strips, tubes, and customized fabricated components in different thicknesses and tempers.

Yes. Aluminum 5005 is highly suitable for anodizing and is commonly selected for decorative applications requiring uniform and high-quality surface finishes.

Common tempers include O (annealed), H12, H14, H32, H34, H36, and H38, which provide different levels of hardness and mechanical strength.

Yes. IranCorps can assist international buyers in sourcing and supplying Aluminum Alloy 5005 from reliable manufacturers with different grades, dimensions, tempers, and commercial specifications according to customer requirements.
