Aluminum Alloy 1060

Aluminum Alloy 1060 is a commercially pure aluminum grade from the 1000 series, containing a minimum of 99.6% aluminum. This alloy is widely recognized for its excellent corrosion resistance, high electrical and thermal conductivity, superior formability, and outstanding welding performance. Due to its high purity and low alloying element content, Aluminum 1060 is mainly selected for applications where conductivity, surface quality, and ease of fabrication are more important than high mechanical strength.

Aluminum Alloy 1060 is commercially available in various forms including aluminum sheets, plates, coils, strips, foils, bars, rods, tubes, and extruded profiles. Common tempers include O (annealed), H12, H14, H16, H18, and H24, which provide different levels of hardness and mechanical properties according to customer requirements. This alloy is extensively used in electrical industries for busbars, transformer components, cable shielding, and conductive parts due to its excellent electrical performance.

The main industrial applications of Aluminum Alloy 1060 include electrical equipment, heat exchangers, HVAC systems, chemical processing equipment, food packaging, lighting reflectors, solar applications, architectural panels, and decorative components. Its lightweight structure, high corrosion resistance, recyclability, and cost efficiency make it a preferred choice for many international B2B buyers looking for reliable pure aluminum materials. Aluminum 1060 can be supplied according to international standards with customized dimensions, surface finishes, and packaging options for global export markets.

Aluminum Alloy 1060 Technical Specification

Property	Specification
Alloy Grade	Aluminum Alloy 1060
Aluminum Content	Min. 99.60%
Alloy Series	1000 Series Pure Aluminum
Material Type	Wrought Aluminum Alloy
Density	Approx. 2.70 g/cm³
Temper Grades	O, H12, H14, H16, H18, H24
Tensile Strength	75 – 110 MPa
Yield Strength	35 – 90 MPa
Electrical Conductivity	Approx. 61-62% IACS
Thermal Conductivity	Approx. 230 W/m·K
Corrosion Resistance	Excellent
Weldability & Formability	Excellent

IF YOU ARE WILLING TO BUY ALLUMINIUM ALLOY 1060 FROM IRANIAN SUPPLIERS, PLEASE SCROLL DOWN AND SUBMIT YOUR REQUEST.

Rated 0 out of 5

0 reviews

Rated 5 out of 5

0

Rated 4 out of 5

0

Rated 3 out of 5

0

Rated 2 out of 5

0

Rated 1 out of 5

0

Reviews

Clear filters

There are no reviews yet.

Be the first to review “Aluminum Alloy 1060”

You must be logged in to post a review.

FAQ Aluminum Alloy 1060

Aluminum Alloy 1060 is mainly used for electrical components, heat exchangers, aluminum foil, chemical equipment, lighting reflectors, food packaging, and architectural applications where high purity and corrosion resistance are required.

The main advantages include excellent corrosion resistance, high electrical conductivity, superior thermal conductivity, lightweight structure, easy forming, good weldability, and excellent surface finishing capability.

Aluminum 1060 can be supplied as sheets, plates, coils, strips, foils, tubes, bars, rods, and customized extruded profiles based on industrial requirements.

Yes. Due to its high electrical conductivity and purity, Aluminum 1060 is widely used in busbars, transformer components, electrical connectors, cable shielding, and power equipment.

Yes. Aluminum 1060 products can be supplied with customized thickness, width, length, surface finish, temper condition, and export packaging according to buyer specifications.

Yes. IranCorps provides sourcing and international supply solutions for Aluminum Alloy 1060 from reliable manufacturers, offering customized specifications, competitive pricing, technical documentation, and export support for global B2B customers.
