Electric Motor (Permanent Magnet DC )

A Permanent Magnet DC Motor (PMDC Motor) uses permanent magnets instead of electromagnets to generate the magnetic field needed for its operation.

In PMDC motors, the armature rotates due to a mechanical force induced by the magnetic field when current flows through its windings, according to Fleming’s left-hand rule. The PMDC motor features a simple design with a stator that houses permanent magnets and an armature with windings and a commutator. PMDC motors are efficient and cost-effective as they require no external power for field excitation and have fewer parts, making them compact. These motors are ideal for low-power applications where complex speed controls are unnecessary, such as in toys ,commonly used as a starter motor in automobiles, windshield wipers, washers, blowers used in heaters and air conditioners ,computer disc drives and in many more.

The advantages of a PMDC motor are:

No need of field excitation arrangement.
No input power in consumed for excitation which improve efficiency of DC motor.
No field coil hence space for field coil is saved which reduces the overall size of the motor.
Cheaper and economical for fractional kW rated applications.

Specification	Details
Product Type	Permanent Magnet DC Electric Motor
Equivalent Names	PMDC Motor, DC Permanent Magnet Motor
Motor Type	Brushed or Customized Permanent Magnet DC Motor
Power Range	Available in Various Power Ratings According to Application
Voltage Range	6V, 12V, 24V, 48V and Customized DC Voltages
Magnet Type	Ferrite, Neodymium (NdFeB), or Other Permanent Magnets
Speed Range	Various RPM Options Available
Torque Performance	High Starting Torque and Adjustable Output Torque
Housing Material	Aluminum Alloy, Steel, or Customized Materials
Protection Class	IP Ratings Available According to Operating Conditions
Applications	Robotics, Automation, Vehicles, Pumps, Fans, Tools
Standards	IEC and International Electric Motor Manufacturing Standards

IF YOU ARE WILLING TO BUY ELECTRIC MOTORS FROM VERIFIED IRANIAN SUPPLIERS, PLEASE SCROLL DOWN AND SUBMIT YOUR REQUEST.

Rated 0 out of 5

0 reviews

Rated 5 out of 5

0

Rated 4 out of 5

0

Rated 3 out of 5

0

Rated 2 out of 5

0

Rated 1 out of 5

0

Reviews

Clear filters

There are no reviews yet.

Be the first to review “Electric Motor (Permanent Magnet DC )”

You must be logged in to post a review.

FAQ Electric Motor (Permanent Magnet DC )

A Permanent Magnet DC Electric Motor is a motor that uses permanent magnets to generate a magnetic field and convert direct current electrical energy into mechanical rotation with high efficiency and reliable performance.

PMDC Motors provide high starting torque, compact design, excellent speed control, efficient energy consumption, fast response, and easy integration with DC power systems.

Permanent Magnet DC Motors are manufactured using permanent magnets, copper windings, electrical steel laminations, shafts, bearings, brushes, commutators, and durable metal housings.

These motors are widely used in robotics, automation systems, electric vehicles, battery-powered equipment, medical devices, industrial machinery, pumps, fans, and actuator systems.

You can find a suitable supplier in Iran through Irancorps, which helps international buyers connect with verified Iranian manufacturers and suppliers according to their technical and commercial requirements.

Buyers should consider voltage, power output, speed, torque, motor efficiency, magnet type, operating environment, protection rating, mounting design, quality standards, and supplier production capability.
